VF-2S
Ultracompact high pressure dust collector



Mold filter


Manual shaking


General dry dust


Max. static pressure


Max. airflow
Amano will provide you cost effective quality products, solutions and services coupled with comprehensive after-sale support that meet the needs of the market.


Features:

  1. Continuous operation for 24 hours
  2. Ultra-compact design
  3. High static pressure 20kPa
  4. Energy saving
  5. "Smallest unit of dust collector"
  6. Filter cleaning (dust removal) by manual shaking
Ultra compact
Ultra static pressure
Durable for continuous operation
Mold cartridge filter
Standard material: Polyester
Surface treatment: -
Corresponding models: VF-2S
Application: General dry dust with particle size of about 10μm
Heat resistant temperature: 40 °C ( 104 °F )
Filtration performance: Good Optional filter: Finefil filter, Anti-Electrostatic filter, Finefil + Anti-Electrostatic filter
If you are looking for dust collector like vacuum cleaner with strong static pressure and durable enough for 24 h operation, Must choose VF-2S.
Strong

It has a strong suction power that is about 7 times that of standard dust collector. Lift the bowling ball!
Small

ECO Energy-Saving

MPC system "Energy-Saving Mode" normally operates at the set high Air Flow, but when it is Idling time energy-saving function that cuts excess power.

Various Options

Application

Dental Works

Manufacturing

Electronics

Food Processing
External View

Front View

Side View

Top View

Specification

Particular Unit VF-2S VF-2S
Power Supply Volt 3-Phase 200V 50Hz 1-Phase 100V 50Hz
Output kW/HP 1.0/1.3 1.0/1.3
Max Airflow m³/min 2.7 2.5
Max. Static Pressure kPa 20 17
Filter Area 0.67 0.67
Suction Port Ø mm 50.8 50.8
Dimension (WxDxH) mm 395x342x399 395x342x399
Weight kg 26 29
